Deuod dan arweiniad

led module smd 2835

Nodweddion Cynnyrch o 2835 1w sbectrwm llawn dan arweiniad smd:

Brand sglodion: Sanan, Epistar, CREE, ac ati.

Mynegai rendro lliw: 70; 80; 90

Fflwcs luminous: 20-22LM; 24-26LM; 27-30LM; 30-32LM; 50-55LM; 55-60LM; 60-65LM; 65-70LM;

Foltedd Ymlaen: 3V, 6V, 9V, 18V, 36V, 48V

Manylebau:

2835 MANYLION CYFRES LED
Enw Cynnyrch	Lliw Golau	CCT/Tonfedd	foltedd	Cyfredol	Lumen	Sylwadau
0.2W 2835 LED	Melyn Aur	1800-2000K	2.8-3.4V	60mA	24-30LM	CRI80,90
0.2W 2835 LED	Gwyn	3000-6500K	2.8-3.4V	60mA	24-34LM	CRI80,90,96 a mwy
0.5W 2835 LED	Gwyn	3000-6500K	2.8-3.4V	150mA	55-75LM	CRI80,90,96 a mwy
1W 2835 LED	Gwyn	3000-6500K	6/9/18/36V	150/100/50/30mA	90-150LM	Cyfres Foltedd Uchel
2835 UV LED	UV	365-410nm	3/6/9V	60/150/175/100mA	/	0.2W, 0.5W, 1W
2835 LED Glas	Glas	440-470nm	3/6/9V	60/150/175/100mA	4-20LM	0.2W, 0.5W, 1W
2835 LED Gwyrdd	Gwyrdd	520-530nm	3/6/9V	60/150/175/100mA	18-80LM	0.2W, 0.5W, 1W
2835 Ambr LED	Melyn/Ambr	590-610nm	2/4/6V	60/150/175/100mA	6-20LM	0.2W, 0.5W, 1W
2835 LED coch	Coch	620-630nm	2/4/6V	60/150/175/100mA	8-30LM	0.2W, 0.5W, 1W
2835 Coch Pell	Coch Pell	660-665nm	2/4/6V	60/150/175/100mA	3-12LM	0.2W, 0.5W, 1W
2835 IR LED	IR	730-750nm	2/4/6V	60/150/175/100mA	/	0.2W, 0.5W, 1W
2835 IR LED	IR	850nm	2/4/6V	60/150/175/100mA	/	0.2W, 0.5W, 1W
2835 PC Glas	Ffosffor Glas	450-470nm	3/6/9V	60/150/175/100mA	6-30LM	0.2W,0.5W,1W WD wedi'i addasu, WP
2835 PC Gwyrdd	Gwyrdd Ffosffor	510-530nm	3/6/9V	60/150/175/100mA	18-120LM
2835 Lliw PC	Ffosffor Ambr/Coch	600-630nm	3/6/9V	60/150/175/100mA	10-60LM
